1 Daily joke

Smart: Guy Creates An AI Clone Of Himself To Sit In On Zoom Meetings So He Doesn't Have To

2 Final project

3 Inspiration for finishing your term projects

1. The Underhanded C Contest

   "The goal of the contest is to write code that is as readable, clear, innocent and straightforward as possible, and yet it must fail to perform at its apparent function. To be more specific, it should do something subtly evil. Every year, we will propose a challenge to coders to solve a simple data processing problem, but with covert malicious behavior. Examples include miscounting votes, shaving money from financial transactions, or leaking information to an eavesdropper. The main goal, however, is to write source code that easily passes visual inspection by other programmers."

2. The International Obfuscated C Code Contest

3. https://www.awesomestories.com/asset/view/Space-Race-American-Rocket-Failures

   Moral: After early disasters, sometimes you can eventually get things to work.

4. The 'Wrong' Brothers Aviation's Failures (1920s)

5. Early U.S. rocket and space launch failures and explosion

4 Software tips

mkdir PROJECT; cd PROJECT

git init

git branch MYBRANCHNAME

git checkout MYBRANCHNAME

vi, make, ....

git add .; git commit -mCOMMENT

5 Exascale computing

https://www.nextplatform.com/2019/12/04/openacc-cozies-up-to-c-c-and-fortran-standards/

https://www.nextplatform.com/2019/01/09/two-thirds-of-the-way-home-with-exascale-programming/

They agree with me that fewer bigger parallel processors are better than many smaller processors connected with MPI. I.e., they like my priorities in this course.

6 CPPCON

CppCon is the annual, week-long face-to-face gathering for the entire C++ community. https://cppcon.org/

https://cppcon2018.sched.com/

CppCon 2014: Herb Sutter "Paying for Lunch: C++ in the ManyCore Age" https://www.youtube.com/watch?v=AfI_0GzLWQ8

CppCon 2016: Combine Lambdas and weak_ptrs to make concurrency easy (4min) https://www.youtube.com/watch?v=fEnnmpdZllQ

A Pragmatic Introduction to Multicore Synchronization by Samy Al Bahra. https://www.youtube.com/watch?v=LX4ugnzwggg

CppCon 2018: Tsung-Wei Huang “Fast Parallel Programming using Modern C++” https://www.youtube.com/watch?v=ho9bqIJkvkc&list=PLHTh1InhhwT7GoW7bjOEe2EjyOTkm6Mgd&index=13

CppCon 2018: Anny Gakhokidze “Workflow hacks for developers” https://www.youtube.com/watch?v=K4XxeB1Duyo&list=PLHTh1InhhwT7GoW7bjOEe2EjyOTkm6Mgd&index=33

CppCon 2018: Bjarne Stroustrup “Concepts: The Future of Generic Programming (the future is here)” https://www.youtube.com/watch?v=HddFGPTAmtU

CppCon 2018: Herb Sutter “Thoughts on a more powerful and simpler C++ (5 of N)” https://www.youtube.com/watch?v=80BZxujhY38

CppCon 2018: Jefferson Amstutz “Compute More in Less Time Using C++ Simd Wrapper Libraries” https://www.youtube.com/watch?v=80BZxujhY38

CppCon 2018: Geoffrey Romer “What do you mean "thread-safe"?” https://www.youtube.com/watch?v=s5PCh_FaMfM

7 Supercomputing conference

https://supercomputing.org/

"The International Conference for High Performance Computing, Networking, Storage, and Analysis"

8 Jack Dongarra

He has visited RPI more than once.

Algorithms for future emerging technologies (2:55:45) https://www.youtube.com/watch?v=TCgHNMezmZ8

Stony Brook talk https://www.youtube.com/watch?v=D1hfrtoVZDo

9 Course survey

I see my role as a curator, selecting the best stuff to present to you. Since I like the topic, and asked to be given permission to create this course, I pick things I like since you might like them too.

So, if you liked the course, then please officially tell RPI by completing the survey and saying what you think. Thanks.

10 After the semester

I'm open to questions and discussions about any legal ethical topic. Even after you graduate.

1 Final project presentations

2 Quantum Summary Page

My quantum computing intro.

qiskit, etc.

3 Using various quantum computers

1. https://arcb.csc.ncsu.edu/~mueller/qc/qc-tut/

2. https://quantumcomputingreport.com/tools/

3. https://quantum-computing.ibm.com/

4. https://aws.amazon.com/braket/

1 Final project presentations

2 My Quantum Summary Page

My quantum computing intro.

no cloning, technologies, qiskit, etc.

3 Using IBM's quantum computer

https://quantum-computing.ibm.com/

1 Deliverables

2 Quantum computing ctd

3 My Quantum Summary Page

continued from Quantum Properties, plus

1. What is an Ion Trap Quantum Computer? Simon Benjamin (2:30).

2. What is Quantum Annealing?, D-Wave Systems (6:14).

   Elementary but sets the stage.

3. How The Quantum Annealing Process Works, D-Wave Systems (6:09)

1 Student project proposals

1. 1-2 minute presentations.

2. Upload your proposal to Gradescope, homework 10.

2 Quantum computing intro, 3

1 Quantum computing intro, 2

1. My quantum computing intro.

   1. try again to watch a few videos.

      1. Visualization of superposition | QuTech Academy (0:44)

      2. David Deutsch - Why is the Quantum so Strange? (8:43)

      3. Quantum Computing for Computer Scientists (1:28:30), the 1st 1/2 hour.

      4. Quantum Algorithms (2:52)

         Which problems can quantum computers solve exponentially faster than classical computers? David Gosset, IBM quantum computing research scientist, explains why algorithms are key to finding out.

      5. Quantum Computing 2020 Update 11:58.

   2. then starting from 4 Algorithm details in my summary.

1 Final projects

1. See the syllabus.

2. April 19: team and title, and 1-2 minute proposal presentation to class.

3. April 26: 100 word project report.

4. April 26, 29, or May 3: 10-15 minute presentations. Email me with preferred dates.

5. May 5: report due.

2 Thrust, concl

1. Universal_vector uses unified memory. No need for host vs device. E.g.,

   /parclass/2021/files/thrust/rpi/tiled_range2u.cu vs tiled_range2.cu

2. This might have a 2x performance penalty. Dunno.

3. You can force a function to execute on the host, or on the device, with an extra 1st argument.

4. There are compiler switches to define what the host or device should be. Common devices are host single thread, host OpenMP, host TBB, GPU. You could conceivably add your own.

   The theory is that no source code changes are required.

3 Several parallel Nvidia tools

1. OpenMP, OpenACC, Thrust, CUDA, C++17, ...

2. https://developer.nvidia.com/blog/accelerating-standard-c-with-gpus-using-stdpar/

3. https://developer.nvidia.com/hpc-compilers

4. There are other interesting pages.

5. To the first order, they have similar performance. That's dominated by data transfer, which they do the same.

6. C++17 may have the greatest potential, but I don't know whether it's mature enough yet.

4 Nvidia GTC

1. This week, free. https://www.nvidia.com/en-us/gtc/

2. Jensen Huang's keynote should be good.

3. Browse around.

5 My parallel research

1. I use thrust (and OpenMP) to for some geometry (CAD or GIS) research doing efficient algorithms on large datasets.

2. One example is to process a set of 3D points to find all pairs closer than a given distance.

3. Another is to overlay two polyhedra or triangulations to find all intersecting pieces. That uses big rational arithmetric to avoid roundoff errors and Simulation of Simplicity to handle degenerate cases.

6 Quantum computing intro, 1

1. Quantum Ideas Virtual Summer School at Duke.

2. My quantum computing intro.

3. Random news

   1. Press release: https://www.techerati.com/news-hub/quantum-brilliance-unveils-server-sized-quantum-computer/

1 Day off

Next Thurs Apr 8 is ECSE Wellness Day. There will be no class.

2 Thrust, ctd

1 Optional day off

Would the class like a day off in the next week or two?

2 Thrust

1. Stanford's parallel course notes.

   Starting at Lecture 8, slide 22.

   Lectures 9 and later will be left for you to browse if you're interested.

2. IMO the syntax for the zip iterator could have been simpler. When I use it, I wrap it in a simpler interface.

3. Nvidia has (at least) 3 official locations for Thrust, and they don't all have the same version, and don't necessarily have docs and examples.

   1. As part of CUDA, /local/cuda/targets/x86_64-linux/include/thrust/

   2. As part of the HPC.

   3. In the github repository, https://github.com/NVIDIA/thrust

4. The most comprehensive doc is online at https://docs.nvidia.com/cuda/thrust/index.html

   This is up-to-date, and precise. However, it is only a summary.

5. There is also http://thrust.github.io/doc/index.html , but it is badly written and slightly obsolete.

6. There are easy-to-read various tutorials online. However they are mostly obsolescent. E.g., they don't use C++-11 lambdas, which are a big help.

7. Also, none of the non-Nvidia docs mention the recent unified memory additions.

8. Look at some Thrust programs and documentation in 2021/files/thrust/

9. There are other alternatives like Kokkos.

10. The alternatives are lower-level (= faster and harder to use) and newer (= possibly less debugged, fewer users).

11. For awhile it looked like Nvidia had stopped developing Thrust, but they've started up again. Good.

12. On parallel in 2021/files/thrust/ are many little demo programs from the thrust distribution, with my additions.

13. Thrust is fast because the functions that look like they would need linear time really take only log time in parallel.

14. In functions like reduce and transform, you often see an argument like thrust::multiplies<float>(). The syntax is as follows:

    1. thrust::multiplies<float> is a class.

    2. It overloads operator().

    3. However, in the call to reduce, thrust::multiplies<float>() is calling the default constructor to construct a variable of class thrust::multiplies<float>, and passing it to reduce.

    4. reduce will treat its argument as a function name and call it with an argument, triggering operator().

    5. You may also create your own variable of that class, e.g., thrust::multiplies<float> foo. Then you just say foo in the argument list, not foo().

    6. The optimizing compiler will replace the operator() function call with the defining expression and then continue optimizing. So, there is no overhead, unlike if you passed in a pointer to a function.

15. Sometimes, e.g., in saxpy.cu, you see saxpy_functor(A).

    1. The class saxpy_functor has a constructor taking one argument.

    2. saxpy_functor(A) constructs and returns a variable of class saxpy_functor and stores A in the variable.

    3. The class also overloads operator().

    4. (Let's call the new variable foo). foo() calls operator() for foo; its execution uses the stored A.

    5. Effectively, we did a closure of saxpy_functor; this is, we bound a property and returned a new, more restricted, variable or class.

1 Student talks

1. Connor. cloud-based/docker-base parallel computing.

2. Isaac. Aerospace.

3. Jack. Nvidia's autonomous machines.

2 Several forms of C++ functions

1. Traditional top level function

   auto add(int a, int b) { return a+b;}

   You can pass this to a function. This really passes a pointer to the function. It doesn't optimize across the call.

2. Overload operator() in a new class

   Each different variable of the class is a different function. The function can use the variable's value. This is a closure.

   This is local to the containing block.

   This form optimizes well.

3. Lambda, or anon function.

   auto add = [](int a, int b) { return a+b;};

   This is local to the containing block.

   This form optimizes well.

4. Placeholder notation.

   As an argument in, e.g., transform, you can do this:

   transform(..., _1+_2);

   This is nice and short.

   As this is implemented by overloading the operators, the syntax of the expression is limited to what was overloaded.

3 Thrust

1. Thrust is an API that looks like STL. Its backend can be GPU-CUDA, OpenMP, TBB, or sequential host-based code.

2. Functional-programming philosophy.

3. Easier programming, once you get used to it.

4. Code is efficient.

5. Uses some unusual C++ techniques, like overloading operator().

6. Since the Stanford slides were created, Thrust has adopted unified addressing, so that pointers know whether they are host or device.

7. Stanford's parallel course notes.

We'll start lecture 8, which has a lot of content. Today we did up thru slide 24.

1 Student talks

2 Thrust

1. Stanford's parallel course notes.

We'll finish lecture 7. We've seen, importantly, optimizing techniques and parallel paradigms. Then we'll see Thrust. 7 presents segmented scan, which is quite useful.

1 Student talks

2 Nvidia GPU and accelerated computing, 9

This is from https://developer.nvidia.com/teaching-kits-downloads This material accompanies Programming Massively Parallel Processors A Hands-on Approach, Third Edition, David B. Kirk Wen-mei W. Hwu. I recommend it. (The slides etc are free but the book isn't.)

My local copy of what I'm using is in /parclass/2021/files/nvidia/GPU-Teaching-Kit-Accelerated-Computing.zip

Today we'll start from Module_20_Related_Programming_Models_OpenCL/

3 OpenCL

1. Module 20.

2. Apple's competition to CUDA.

3. is largely CUDA but they changed the names and made it look like OpenGL and clunkier.

4. not interesting so long as Nvidia is dominant.

4 Nvidia primary documentation

Generally more up-to-date and accurate, but drier. A little disorganized because it keeps growing. The root is here: https://docs.nvidia.com/

Two major relevant sets are:

1. https://docs.nvidia.com/hpc-sdk/index.html

2. https://docs.nvidia.com/cuda/index.html

5 Other Nvidia features

We've seen almost everything, except:

1. Texture and surface maps.

2. ML HW like A=BC+D for 4x4 matrices.

3. Ray tracing HW, to compute a ray's intersections with boxes.

4. Cooperative groups: with Ampere, subsets of a warp can synchronize.

5. Subsets of a GPU can be defined as virtual GPUS, which are walled off from each other.

6. Memory can be compressed when stored, making a space-time tradeff.

7. The terminology CUDA core is obsolete. Now, they say that an SM has, perhaps 32 single float units, 32 integer units, 32 CUDA instruction dispatchers, and 16 double float units, etc. Each unit operates independently.

6 Nvidia conceptual hierarchy

As always, this is as I understand it, and could be wrong. Nvidia uses their own terminology inconsistently. They may use one name for two things (E.g., Tesla and GPU), and may use two names for one thing (e.g., module and accelerator). As time progresses, they change their terminology.

1. At the bottom is the hardware micro-architecture. This is an API that defines things like the available operations. The last several Nvidia micro-architecture generations are, in order, Tesla (which introduced unified shaders), Fermi, Kepler, Maxwell (introduced in 2014), Pascal (2016), and Volta (2018).

2. Each micro-architecture is implemented in several different microprocessors. E.g., the Kepler micro-architecture is embodied in the GK107, GK110, etc. Pascal is GP104 etc. The second letter describes the micro-architecture. Different microprocessors with the same micro-architecture may have different amounts of various resources, like the number of processors and clock rate.

3. To be used, microprocessors are embedded in graphics cards, aka modules or accelerators, which are grouped into series such as GeForce, Quadro, etc. Confusingly, there is a Tesla computing module that may use any of the Tesla, Fermi, or Kepler micro-architectures. Two different modules using the same microprocessor may have different amounts of memory and other resources. These are the components that you buy and insert into a computer. A typical name is GeForce GTX1080.

4. There are many slightly different accelerators with the same architecture, but different clock speeds and memory, e.g. 1080, 1070, 1060, ...

5. The same accelerator may be manufactured by different vendors, as well as by Nvidia. These different versions may have slightly different parameters. Nvidia's reference version may be relatively low performance.

6. The term GPU sometimes refers to the microprocessor and sometimes to the module.

7. There are at least four families of modules: GeForce for gamers, Quadro for professionals, Tesla for computation, and Tegra for mobility.

8. Nvidia uses the term Tesla in two unrelated ways. It is an obsolete architecture generation and a module family.

9. Geoxeon has a (Maxwell) GeForce GTX Titan and a (Kepler) Tesla K20xm. Parallel has a (Volta) RTX 8000 and (Pascal) GeForce GTX 1080. We also have an unused (Kepler) Quadro K5000.

10. Since the highest-end (Tesla) modules don't have video out, they are also called something like compute modules.

7 GPU range of speeds

Here is an example of the wide range of Nvidia GPU speeds; all times are +-20%.

The Quadro RTX 8000 has 4608 CUDA cores @ 1.77GHz and 48GB of memory. matrixMulCUBLAS runs at 5310 GFlops. The specs claim 16 TFlops. However those numbers understate its capabilities because it also has 576 Tensor cores and 72 ray tracing cores to cast 11G rays/sec.

The GeForce GTX 1080 has 2560 CUDA cores @ 1.73GHz and 8GB of memory. matrixMulCUBLAS runs at 3136 GFlops. However the reported time (0.063 msec) is so small that it may be inaccurate. The quoted speed of the 1080 is about triple that. I'm impressed that the measured performance is so close.

The Quadro K2100M in my Lenovo W540 laptop has 576 CUDA cores @ 0.67 GHz and 2GB of memory. matrixMulCUBLAS runs at 320 GFlops. The time on the GPU was about .7 msec, and on the CPU 600 msec.

It's nice that the performance almost scaled with the number of cores and clock speed.

8 CUDA

9 Types of memory allocation

Here's a brief overview of my understanding of the various places that you can assign memory in a program.

1. Static. Define a fixed-size array global array. The variable is constructed at compile time, so accesses might perhaps be faster. Global vars with non default initial values increase the executable file size. If they're large enough, you need to use the compiler option -mcmodel=medium or -mcmodel=large. They cause the compiler to generate wider addresses. I don't know the effect on the program's size or speed, but suspect that it's small.

2. Stack. Define local arrays, that are created and freed as the routine is entered and exited. Their addresses relative to the base of this call frame may be constant. The default stack size is 8MB. You can increase this with the command ulimit or in the program as shown in stacksize.cc. I believe that in OpenMP, the max stacksize may be allocated when each thread is created. Then, a really big stackssize might have a penalty.

3. Heap. You use new and destroy. Variables are constructed whenever you want. The more objects on the heap, the more time that each new or destroy takes. If you have lots of objects consider using placement new or creating an array of them.

   For CUDA, some variables must be on the heap.

I like to use static, then stack, and heap only when necessary. However, allocating few but large, blocks on the heap is also fast.

Google's allocator is noticeably better than the default one. To use it, link your programs with -ltcmalloc. You can often use it on an existing executable foo thus:

LD_PRELOAD="/usr/lib/libtcmalloc.so" foo

I found it to save 15% to 30% in time.

Another memory concern is speed. Parallel has a NUMA (Non Uniform Memory Architecture). It has two 14-core Xeons. Each core has 128GB of main memory. Although all 256GB are in a common address space, accessing memory on same core as the thread is running on is faster.

The following is what I think based on some research, but may be wrong: A 4KB page of memory is assigned to a specific core when it is first written (not when it is reserved). So, each page of a large array may be on a different core. This can be used to optimize things. This gets more fun with 8-processor systems.

All that is separate from cache issues.

You can also assign your OpenMP threads to specific cores. This affects speed in ways I don't understand. The issues are resource sharing vs conflicts.

10 Nvidia GPU summary

Here's a summary of the Nvidia Pascal GP104 GPU architecture as I understand it. It's more compact than I've found elsewhere. I'll add to it from time to time. Some numbers are probably wrong.

1. The host is the CPU.

2. The device is the GPU.

3. The device contains 20 streaming multiprocessors (SMs).

   Different GPU generations have used the terms SMX or SMM.

4. A thread is a sequential program with private and shared memory, program counter, etc.

5. Threads are grouped, 32 at a time, into warps.

6. Warps of threads are grouped into blocks.

   Often the warps are only implicit, and we consider that the threads are grouped directly into blocks.

   That abstract hides details that may be important; see below.

7. Blocks of threads are grouped into a grid, which is all the threads in the kernel.

8. A kernel is a parallel program executing on the device.

   1. The kernel runs potentially thousands of threads.

   2. A kernel can create other kernels and wait for their completion.

   3. There may be a limit, e.g., 5 seconds, on a kernel's run time.

9. Thread-level resources:

   1. Each thread can use up to 255 fast registers. Registers are private to the thread.

      All the threads in one block have their registers allocated from a fixed pool of 65536 registers. The more registers that each thread uses, the fewer warps in the block can run simultaneously.

   2. Each thread has 512KB slow local memory, allocated from the global memory.

   3. Local memory is used when not enough registers are available, and to store thread-local arrays.

10. Warp-level resources:

    1. Threads are grouped, 32 at a time, into warps.

    2. Each warp executes as a SIMD, with one instruction register. At each cycle, every thread in a warp is either executing the same instruction, or is disabled. If the 32 threads want to execute 32 different instructions, then they will execute one after the other, sequentially.

       If you read in some NVidia doc that threads in a warp run independently, then continue reading the next page to get the info mentioned in the previous paragraph.

    3. If successive instructions in a warp do not depend on each other, then, if there are enough warp schedulers available, they may be executed in parallel. This is called Instruction Level Parallelism (ILP).

    4. For an array in local memory, which means that each thread will have its private copy, the elements for all the threads in a warp are interleaved to potentially increase the I/O rate.

       Therefore your program should try to have successive threads read successive words of arrays.

    5. A thread can read variables from other threads in the same warp, with the shuffle instruction. Typical operation are to read from the K-th next thread, to do a butterfly permutation, or to do an indexed read. This happens in parallel for the whole warp, and does not use shared memory.

    6. A warp vote combines a bit computed by each thread to report results like all or any.

11. Block-level resources:

    1. A block may contain up to 1024 threads.

    2. Each block has access to 65536 fast 32-bit registers, for the use of its threads.

    3. Each block can use up to 49152 bytes of the SM's fast shared memory. The block's shared memory is shared by all the threads in the block, but is hidden from other blocks.

       Shared memory is basically a user-controllable cache of some global data. The saving comes from reusing that shared data several times after you loaded it from global memory once.

       Shared memory is interleaved in banks so that some access patterns are faster than others.

    4. Warps in a block run asynchronously and run different instructions. They are scheduled and executed as resources are available.

    5. However they are all running the same instruction sequence, perhaps at different points in it.

    6. That is call SPMD, single program multiple data.

    7. The threads in a block can be synchonized with __syncthreads().

       Because of how warps are scheduled, that can be slow.

    8. The threads in a block can be arranged into a 3D array, up to 1024x1024x64.

       That is for convenience, and does not increase performance (I think).

    9. I'll talk about textures later.

12. Streaming Multiprocessor (SM) - level resources:

    1. Each SM has 128 single-precision CUDA cores, 64 double-precision units, 32 special function units, and 32 load/store units.

    2. In total, the GPU has 2560 CUDA cores.

    3. A CUDA core is akin to an ALU. The cores, and all the units, are pipelined.

    4. A CUDA core is much less powerful than one core of an Intel Xeon. My guess is 1/20th.

    5. Beware that, in the CUDA C Programming Guide, NVidia sometimes calls an SM a core.

    6. The limited number of, e.g., double precision units means that an DP instruction will need to be scheduled several times for all the threads to execute it. That's why DP is slower.

    7. Each SM has 4 warp schedulers and 8 instruction dispatch units.

    8. 64 warps can simultaneously reside in an SM.

    9. Therefore up to 32x64=2048 threads can be executed in parallel by an SM.

    10. Up to 16 blocks that can simultaneously be resident in an SM.

        However, if each block uses too many resources, like shared memory, then this number is reduced.

        Each block sits on only one SM; no block is split. However a block's warps are executed asynchronously (until synced).

    11. Each SM has 64KiB (?) fast memory to be divided between shared memory and an L1 cache. Typically, 48KiB (96?) is used for the shared memory, to be divided among its resident blocks, but that can be changed.

    12. The 48KB L1 cache can cache local or global memory.

    13. Each SM has a read-only data cache of 48KB to cache the global constant memory.

    14. Each SM has 8 texture units, and many other graphics capabilities.

    15. Each SM has 256KB of L2 cache.

13. Grid-level resources:

    1. The blocks in a grid can be arranged into a 3D array. up to \((2^{31}-1, 2^{16}-1, 2^{16}-1)\).

    2. Blocks in a grid might run on different SMs.

    3. Blocks in a grid are queued and executed as resources are available, in an unpredictable parallel or serial order. Therefore they should be independent of each other.

    4. The number of instructions in a kernel is limited.

    5. Any thread can stop the kernel by calling assert.

14. Device-level resources:

    1. There is a large and slow 48GB global memory, which persists from kernel to kernel.

       Transactions to global memory are 128 bytes.

       Host memory can also be memory-mapped into global memory, although the I/O rate will be lower.

       Reading from global memory can take hundreds of cycles. A warp that does this will be paused and another warp started. Such context switching is very efficient. Therefore device throughput stays high, although there is a latency. This is called Thread Level Parallelism (TLP) and is a major reason for GPU performance.

       That assumes that an SM has enough active warps that there is always another warp available for execution. That is a reason for having warps that do not use all the resources (registers etc) that they're allowed to.

    2. There is a 2MB L2 cache, for sharing data between SMs.

    3. There is a 64KiB Small and fast global constant memory, , which also persists from kernel to kernel. It is implemented as a piece of the global memory, made fast with caches.

       (Again, I'm still resolving this apparent contradiction).

    4. Grid Management Unit (GMU) schedules (pauses, executes, etc) grids on the device. This is more important because grids can start other grids (Dynamic Parallelism).

    5. Hyper-Q: 32 simultaneous CPU tasks can launch kernels into the queue; they don't block each other. If one kernel is waiting, another runs.

    6. CUDA Work Distributor (CWD) dispatches 32 active grids at a time to the SMs. There may be 1000s of grids queued and waiting.

    7. GPU Direct: Other devices can DMA the GPU memory.

    8. The base clock is 1607MHz.

    9. GFLOPS: 8873.

    10. Memory bandwidth: 320GB/s

15. GPU-level resources:

    1. Being a Geforce product, there are many graphics facilities that we're not using.

    2. There are 4 Graphics processing clusters (GPCs) to do graphics stuff.

    3. Several perspective projections can be computed in parallel, for systems with several displays.

    4. There's HW for texture processing.

16. Generational changes:

    1. With each new version, Nvidia tweaks the numbers. Some get higher, others get lower.

       1. E.g., Maxwell had little HW for double precision, and so that was slow.

       2. Pascal's clock speed is much higher.

17. Refs:

    1. The CUDA program deviceDrv.

    2. http://developer.download.nvidia.com/compute/cuda/compute-docs/cuda-performance-report.pdf

    3. http://international.download.nvidia.com/geforce-com/international/pdfs/GeForce_GTX_1080_Whitepaper_FINAL.pdf

    4. Better Performance at Lower Occupancy, Vasily Volkov, UC Berkeley, 2010.

    5. https://www.pgroup.com/lit/articles/insider/v2n1a5.htm - well written but old.

    (I'll keep adding to this. Suggestions are welcome.)

11 More CUDA

1. CUDA function qualifiers:

   1. __global__ device function called from host, starting a kernel.

   2. __device__ device function called from device function.

   3. __host__ (default) host function called from host function.

2. CUDA variable qualifiers:

   1. __shared__

   2. __device__ global

   3. __device__ __managed__ automatically paged between host and device.

   4. __constant__

   5. (nothing) register if scalar, or local if array or if no more registers available.

3. If installing CUDA on your machine, this repository seems best:

   http://developer.download.nvidia.com/compute/cuda/repos/ubuntu1604/x86_64

   That includes the Thrust headers but not example programs.

12 Unionfs: Linux trick of the day

1. aka overlay FS, translucent FS.

2. If a, b are directories, and m is an empty directory, then

   unionfs -o cow a=RW:b m

   makes m to be a combo of a and b, with a being higher priority

3. Writing a file into m writes it in a.

4. Changing a file in b writes the new version into a

5. Deleting a file in b causes a white-out note to be stored in a.

6. Unmount it thus:

   fusermount -u m

7. None of this requires superuser.

8. Application: making a read-only directory into a read-write directory.

9. Note: IBM had a commercial version of this idea in its CP/CMS OS in the 1960s.

13 Thrust

1. Stanford's parallel course notes. We did up thru the lecture 6 and parts of 7 and 8.

1 Nvidia GPU and accelerated computing, 8

This is from https://developer.nvidia.com/teaching-kits-downloads This material accompanies Programming Massively Parallel Processors A Hands-on Approach, Third Edition, David B. Kirk Wen-mei W. Hwu. I recommend it. (The slides etc are free but the book isn't.)

My local copy of what I'm using is in /parclass/2021/files/nvidia/GPU-Teaching-Kit-Accelerated-Computing.zip

Today we'll start from Module_16_Case_Study_Electrostatic_Potential_Calculation/Slides/Lecture-16-1-VMD-case-study-Part1.pdf

1 Nvidia GPU and accelerated computing, 7

This is from https://developer.nvidia.com/teaching-kits-downloads

My local copy of what I'm using is in /parclass/2021/files/nvidia/GPU-Teaching-Kit-Accelerated-Computing.zip

Today we'll start from GPU-Teaching-Kit-Accelerated-Computing/Module_10_Parallel_Computation_Patterns_Scan/Slides/Lecture-10-2-work-inefficient-scan-kernel.pdf

This introduces some common parallel programming paradigms. They are useful with any parallel computing platform.

We did up thru 15-2.

1 Types of virtualization

1. There are many possible levels of virtualization.

2. At a low level, one might emulate the HW. This is quite flexible but too slow.

3. At a higher level, a basic OS runs separate virtual machines, each with its own file system.

   1. Harmless machine instructions execute normally.

   2. Powerful ones are trapped and emulated.

   3. This requires a properly designed instruction set.

   4. IBM has been doing this commercially for 40 years, with something originally called CP/CMS.

   5. I think that IBM lucked out with their instruction set design, and didn't plan it.

   6. Well-behaved clients might have problematic code edited before running, to speed the execution.

   7. I think that Vmware does that.

   8. It seems that compute-intensive clients might have almost no overhead.

   9. However, the emulated file system can be pretty bad.

   10. With Vmware, several clients can all be different OSs, and the host can be any compatible OS.

   11. E.g., I've had a linux vmware host simultaneously running both linux and windows clients.

   12. SFAIK, Vmware currently doesn't run on Ubuntu because of recent linux security upgrades requiring that new modules installed in the kernel be signed.

   13. In linux, root no longer has infinite power.

4. The next level of virtualization has an nontrivial host OS, but separates the clients from each other.

   1. They see a private view of the process space, file system, and other resources.

   2. This is lighter weight, e.g., quicker to start a VM and less overhead.

   3. The host and client must be the same OS.

   4. This might be called paravirtualization.

   5. Linux supports this with things like namespace isolation and control groups (cgroups). Wikipedia et al describe this.

5. The next level up is the normal linux security.

   1. You can see all the processes and similar resources.

   2. The file system has the usual protections.

   3. This is hard to make secure when doing something complicated.

   4. How do I protect myself from firefox going bad?

   5. It's easy to describe what it should be allowed to do, but almost impossible to implement.

   6. That includes using apparmor etc.

6. In theory, packaging an app in a virtual machine has fewer dependencies and is more secure.

7. You can run the vm w/o changes on different hosts.

8. A Vmware client can run w/o change on both linux and windows hosts.

9. You can run a client on your own hardware, then spill over to a commercial cloudy platform when necessary.

2 Docker

1. Docker is a popular lightweight virtualization system, which Nvidia uses to distribute SW.

2. Docker runs images that define virtual machines.

3. Docker images share resources with the host, in a controlled manner.

4. For simple images, which is not nvidia/cuda, starting the image is so cheap that you can do it to run one command, and encapsulate the whole process in a shell function.

5. Docker is worth learning, apart from its use by Nvidia for parallel computing. You might also look up Kubernetes.

6. More info:

   1. https://www.docker.com/

   2. https://www.zdnet.com/article/what-is-docker-and-why-is-it-so-darn-popular/

   3. https://opensource.com/resources/what-docker

7. I installed docker on parallel to run nvidia images like pgc++. Then I removed it because it wasn't necessary, was complicated, and it was insecure.

3 Nvidia GPU and accelerated computing, 6

This is from https://developer.nvidia.com/teaching-kits-downloads

My local copy of what I'm using is in /parclass/2021/files/nvidia/GPU-Teaching-Kit-Accelerated-Computing.zip

Today we'll start from Module_9_Parallel_Computation_Patterns_Reduction/Slides/Lecture-9-1-reduction.pdf

This introduces some common parallel programming paradigms.

Today we did thru 10-2.

1 Nvidia GPU and accelerated computing, 5

This is from https://developer.nvidia.com/teaching-kits-downloads

My local copy of what I'm using is in /parclass/2021/files/nvidia/GPU-Teaching-Kit-Accelerated-Computing.zip

Today we'll start from Module_6_Memory_Access_Performance/Slides/Lecture-6-2-memory-coalescing.pdf

We did through 8-4.

2 More info on current Nvidia architecture

We'll cover this in detail later.

https://www.nextplatform.com/2020/05/28/diving-deep-into-the-nvidia-ampere-gpu-architecture/

https://www.nvidia.com/content/dam/en-zz/Solutions/Data-Center/nvidia-ampere-architecture-whitepaper.pdf

1 Nvidia GPU and accelerated computing, 4

This is from https://developer.nvidia.com/teaching-kits-downloads

My local copy of what I'm using is in /parclass/2021/files/nvidia/GPU-Teaching-Kit-Accelerated-Computing.zip

Today we'll start from Module_2_Introduction_to_CUDA_C/Slides/Lecture-3-5-transparent-scaling.pdf

We did up through 6.1.

1 Nvidia GPU and accelerated computing, 3

This is from https://developer.nvidia.com/teaching-kits-downloads

My local copy of what I'm using is in /parclass/2021/files/nvidia/GPU-Teaching-Kit-Accelerated-Computing.zip

Today we'll start from Module_2_Introduction_to_CUDA_C/Slides/Lecture-2-3-cuda-parallelism-threads.pdf

1 Compilers on parallel.ecse

To access them, source /opt/nvidia/initenvs

2 Nvidia GPU and accelerated computing, 2

This is from https://developer.nvidia.com/teaching-kits-downloads

My local copy of what I'm using is in /parclass/2021/files/nvidia/GPU-Teaching-Kit-Accelerated-Computing.zip

Today we'll start from Module_2_Introduction_to_CUDA_C/Slides/Lecture-2-4-cuda-toolkit.pdf .

We'll also look at programs in LabsandSolutions/ . We'll see debugging tools like cuda-gdb and cuda-memcheck.

1 Link to lecture videos

is now in the top menu bar.

2 How I show files from parallel.ecse to the class

Especially graphics stuff like PDFs. The problem is that graphics over ssh is slow.

/parclass is a git repository. There's a copy on my local laptop. I display from that.

3 OpenACC concluded

I recommend OpenACC for Programmers: Concepts and Strategies By Sunita Chandrasekaran, Guido Juckeland. Informit, Amazon. Github.

Chapter 4 is online for free as PDF and html.

We'll try a program. Note how using

export PGI_ACC_TIME=1

causes timing info to be printed.

4 Nvidia GPU and accelerated computing

This is from https://developer.nvidia.com/teaching-kits-downloads

My local copy of what I'm using is in /parclass/2021/files/nvidia/GPU-Teaching-Kit-Accelerated-Computing.zip

We'll spend several classes on this topic, speed reading through the slides.

Even though these slides are dated 2020, they have some obsolescent ideas, like explicitly copying data between host and device.

Also, some terminology is not standardized, and may be inconsistent. Even in Nvidia docs.

Today we did up through Module_2_Introduction_to_CUDA_C/Slides/Lecture-2-3-cuda-parallelism-threads.pdf .

5 Archivemount

This is today's programmer productivity tip, unrelated to parallel computing but generally useful.

Rather than explicitly extracting large zip archives or tarballs in order to read files in them, I use archivemount to create a virtual file system. This saves disk space. It doesn't stress git as much (fewer files). When reading, the I/O time is insignificantly increased. For some formats, you can even write. You can have more confidence that the zip file wasn't changed, than in a directory with perhaps hundreds of files.

Rules

1. Submit the answers to Gradescope.

2. You may do homeworks in teams of 2 students. Create a gradescope team and make one submission with both names.

Question

Download, run, and compile the sample programs in Chapter 4 of OpenACC for Programmers: Concepts and Strategies. Report your experience comparing the serial, openmp, and openacc versions.

1 Compilers ctd

1. I installed Nvidia's compiler suite on parallel into /opt/nvidia

2. Make them available to you by sourcing /opt/nvidia/initenvs

3. These are the recommended compilers.

4. They work with Nvidia GPUs better.

5. However g++ produced faster OpenMP code for the Xeon on one example.

2 OpenACC ctd

1. https://www.openacc.org/events/openacc-online-course-2018 weeks 2 and 3.

They also introduce you to Nvidia.

3 Parallel.ecse available

You may use spare time on parallel.ecse for any legal ethical purpose, even unrelated to this course. No running businesses or trying to make money. No mining. However research and having fun are fine.

I was running boinc for https://milkyway.cs.rpi.edu/milkyway/ since 2018, and am user 359 in total credit.

4 New teaching tool

Today's new gimmick is mirroring my ipad to a window on my laptop, so I can use the ipad as a graphics tablet. Relevant SW: uxplay on the laptop; see https://rodrigoribeiro.site/2020/08/09/mirroring-ipad-iphone-screen-on-linux/ and any notetaking tool on the ipad.

Earlier I tried using a laptop with a touch screen. That didn't work well, apparently because of deficiencies with linux SW controlling the screen.

5 Applied EE

My home Tesla powerwalls (27KHW capacity) and solar panels (8KW peak) are finally working. Over the year, my net electrical consumption will be close to zero. I can survive perhaps a 2-day blackout. However the real reason for getting them is that I like gadgets.

6 Changes in this course from 2020 to 2021

1. Drop the attempt to use docker for compilers. It's, complicated, not necessary, and is a security risk.

   However, docker is an important industrial tool. If anyone would like some class time on it, just ask.

2. Use nvc++ not pgc++. nvc++ didn't exist last year.

7 Nvidia GPU and accelerated computing

This is from https://developer.nvidia.com/teaching-kits-downloads

My local copy of what I'm using is in /parclass/2021/files/nvidia/GPU-Teaching-Kit-Accelerated-Computing.zip

Rules

1. Submit the answers to Gradescope.

2. You may do homeworks in teams of 2 students. Create a gradescope team and make one submission with both names.

Question

1. The goal is to measure whether OpenMP actually makes matrix multiplication faster, with and w/o SIMD.

2. You may use anything in /parallel-class/openmp that seems useful.

3. Write a C++ program on parallel.ecse to initialize pseudorandomly and multiply two 100x100 float matrices. One possible initialization:

   a[i][j] = i*3 + (j*j)%5; b[i][j] = i*2 + (j*j)%7;

4. (10 points) Report the elapsed time. Include the program listing.

5. Add an OpenMP pragma to do the work in parallel.

6. (10 points) Report the elapsed time, varying the number of threads thus: 1, 2, 4, 8, 16, 32, 64.

   What do you conclude?

7. (5 points) Repeat that two more times to see how consistent the times are.

8. (10 points) Modify the pragma to use SIMD.

   Report the elapsed time, varying the number of threads thus: 1, 2, 4, 8, 16, 32, 64.

   What do you conclude?

9. (10 points) Compile and run your program with two different levels of compiler optimization: O1 and O3, reporting the elapsed time. Modify your program to prevent the optimizer from optimizing the program away to nothing. E.g., print a few values.

10. (5 points) What do you conclude about everything?

Total: 40 pts.

1 Thursday special lecture: Quantum Computing with Atoms

NY CREATES Emerging Technologies Seminar Series

February 4th (Thursday), 2021: 11:30 am – 12:30 pm (EST)

Zoom Pre-Registration (by Feb 3) required at:

https://ny-creates.org/news-events/ny-creates-events/

“Quantum Computing with Atoms”

by: Dr. Christopher Monroe

2 Our various computer systems don't talk to each other

Everyone in this class should--

1. be in gradescope,

2. have received an invitation to webex meet for the lectures,

3. be reading the messages in webex (formerly called webex teams),

4. be in LMS,

5. be reading this blog.

If you're not in gradescope or webex or webex meet, e.g. because you added late, tell us.

3 Today's student talks

1. Ben: computers 5&6.

2. Connor: machine learning

1 Today's student talks

1. Yunshi: python

2. Justin: Application of Par Comp in Astronomy

3. Dan: physics application

4. Joseph: pthreads

5. Jack: Folding at Home

6. Isaac: MPI

7. Blaine: Matlab

8. Mark: top 2 supercomputers

2 Thursday special lecture: Quantum Computing with Atoms

NY CREATES Emerging Technologies Seminar Series

February 4th (Thursday), 2021: 11:30 am – 12:30 pm (EST)

Zoom Pre-Registration (by Feb 3) required at:

https://ny-creates.org/news-events/ny-creates-events/

“Quantum Computing with Atoms”

by: Dr. Christopher Monroe

Co-Founder & Chief Scientist, IonQ Inc. and Professor, Duke University Abstract: Trapped atomic ions are the unique quantum computing physical platform that features qubits with essentially infinite idle coherence times. Such atomic clock qubits are controlled with laser beams, allowing densely-connected and reconfigurable universal gate sets. Unlike all other physical platforms for quantum computing, the path to scale involves concrete architectural paths, from shuttling ions between QPU cores to modular photonic interconnects between multiple QPUs. Full-stack ion trap quantum computers have thus moved away from the physics of qubits and gates and toward the engineering of optical control signals, quantum gate compilation for algorithms, and high level system design considerations. I will summarize the state-of-the-art in these quantum computers and speculate on how they might be used.

Biography: Christopher Monroe is Professor of ECE and Physics at Duke University and the co-Founder and Chief Scientist of IonQ, Inc. Monroe is an atomic physicist and quantum engineer, specializing in the isolation of individual atoms for applications in quantum information science. At NIST in the 1990s, Monroe co-led the team that demonstrated the first quantum logic gate. At the University of Michigan and the University of Maryland, Monroe’s research group pioneered all aspects of trapped atomic ion based quantum computers, making the first steps toward a scalable, reconfigurable, and modular quantum computer system. In 2016, he co-founded IonQ, a startup company leading the way in the fabrication of full-stack quantum computers. Monroe is a member of the National Academy of Sciences and is one of the key architects of the U.S. National Quantum Initiative passed by Congress in 2018.

Although this is outside the class time, I hope you can watch it. After it's over, I'll start a webex meet to discuss it. That'll be the Thurs class.

Rules

1. Due next Mon 2021-02-08, noon.

2. Submit the answers to Gradescope.

3. You may do homeworks in teams of 2 students. Create a gradescope team and make one submission with both names.

4. Short but informative answers are fine.

Questions

Each is 5 points.

1. Why is one CUDA core less powerful than one Intel Xeon core?

2. If 10% of a program cannot be parallelized, then what is the max speedup even with infinite parallelism?

3. "For short running parallel programs, there can actually be a decrease in performance compared to a similar serial implementation.". Why?

4. What is the difference between strong scaling and weak scaling?

5. What is cache coherency?

6. Define "embarrassingly parallel".

7. How many CUDA cores does the RTX 8000 have?

8. Why have machine cycle speeds stopped increasing?

9. Give an advantage and a disadvantage of shared memory versus distributed memory for parallel computation.

10. In OpenMP, what's the difference between ATOMIC and CRITICAL?

Total: 50 pts.

1 Webex, classes, etc

1. I'll continue to use Webex Meet for awhile because it lets me show the chat window simultaneously.

2. In Webex (formerly called Webex Teams), I have a space for people to talk.

3. Mediasite has recordings of classes.

4. My blog has transcripts and chats. See the Files tab.

2 LLNL parallel tutorial

We'll quickly finish it, starting at Parallel Programming Models. https://computing.llnl.gov/tutorials/parallel_comp/

3 Material

1. Think about these questions.

   1. Why have machine cycle speeds stopped increasing?

   2. What architectures do the top 3 machines on the Top 500 list use?

   3. Which one of the following 4 choices are most GPUs: SISD, SIMD, MISD, MIMD.

   4. Which one of the following 4 choices are most current multicore CPUs: SISD, SIMD, MISD, MIMD.

   5. Per Amdahl's law, if a program is 10% sequential and 90% parallelizable, what is the max speed up that can be obtained with an infinite number of parallel processors?

4 Recently obsoleted parallel tech

1. Intel Xeon Phi

2. IBM BlueGene

5 My research

I do parallel geometry algorithms on large problems for CAD and GIS. See my home page. If this is interesting, talk to me. Maybe you can do something that leads to a jointly-authored paper.

6 parallel.ecse

1. I've set up account for you.

2. Your user name is your rcsid.

3. I'll mention your initial password. Change it.

4. Play with them. I recomend connecting with ssh.

5. From outside RPI, you need to use the vpn.

6. Its accounts are completely separate from RCS; I will use the same userid for convenience. Changing your password on parallel does not affect your RCS password, and vv.

7 OpenMP

1. https://www.openmp.org/ Browse it.

2. Read https://computing.llnl.gov/tutorials/openMP/

3. We'll see some examples running on parallel, at /parclass2021/files/openmp/rpi

4. We saw that running even a short OpenMP program could be unpredictable. The reason for that was a big lesson.

   There are no guarantees about the scheduling of the various threads. There are no guarantees about fairness of resource allocation between the threads. Perhaps thread 0 finishes before thread 1 starts. Perhaps thread 1 finishes before thread 2 starts. Perhaps thread 0 executes 3 machine instructions, then thread 1 executes 1 instruction, then thread 0 executes 100 more, etc. Each time the process runs, something different may happen. One thing may happen almost all the time, to trick you.

1 You

After we discuss the syllabus, tell the class about yourself for a minute or two. What would you like to see in this course.

2 Material

1. Read the syllabus.

2. Read https://computing.llnl.gov/tutorials/parallel_comp/ for an intro to parallel computing.

3. Some points:

   1. Parallel computing is decades old; there were commercial machines in the 1980s. I directed two PhD theses in parallel geometry then. However, then, clocks speeds were increasing so serial machines were more interesting.

   2. Now: physics limits to processor speed.

   3. History of Nvidia.

      1. Curtis Priem had designed graphics HW for both IBM and Sun Microsystems. (For awhile Sun was THE Unix workstation company. They used open standards and had the best price / performance.)

      2. Nvidia designed gaming graphics accelerators...

      3. that just happened to be parallel coprocessors...

      4. that started to be used for nongraphics parallel processing because of their value.

      5. Nvidia noticed that and added more capability, e.g., double precision IEEE floats, to serve that market.

      6. Currently, some of the highest performance Nvidia boards cannot even do graphics because they don't have video out ports.

   1. Intel CPUs vs Nvidia CUDA cores.

   2. Advantages and disadvantages of shared memory.

   3. OpenMP vs CUDA.

   4. Rate-limiting cost usually I/O not computation.

3 Homework 1

is online, due next Mon.

1 Catalog info

Title

ECSE-4740-01 Applied Parallel Computing for Engineers

Semesters

Spring term annually

Credits

3 credit hours

Time and place

Mon and Thurs 12:20-1:40pm, online

2 Description

1. This is intended to be a computer engineering course to provide students with knowledge and hands-on experience in developing applications software for affordable parallel processors. This course will mostly cover hardware that any lab can afford to purchase. It will cover the software that, in the prof's opinion, is the most useful. There will also be some theory.

2. The target audiences are ECSE seniors and grads and others with comparable background who wish to develop parallel software.

3. This course will have minimal overlap with parallel courses in Computer Science. We will not teach the IBM BlueGene, because it is so expensive, nor cloud computing and MPI, because most big data problems are in fact small enough to fit on our hardware.

4. You may usefully take all the parallel courses at RPI.

5. This unique features of this course are as follows:

   1. For 2/3 of the course, use of only affordable hardware that any lab might purchase, such as Nvidia GPUs. This is currently the most widely used and least expensive parallel platform.

   2. Emphasis on learning several programming packages, at the expense of theory. However you will learn a lot about parallel architecture.

6. Hardware taught, with reasons:

   Multicore Intel Xeon

   universally available and inexpensive, comparatively easy to program, powerful

   Nvidia GPU accelerator

   widely available (Nvidia external graphics processors are on 1/3 of all PCs), very inexpensive, powerful, but harder to program. Good cards cost only a few hundred dollars.

   Quantum computers

   It's new and hot and might some day be useful.

7. Software that might be taught, with reasons:

   OpenACC C++ extension

   widely used, easy to use if your algorithm is parallelizable, backend is primarily multicore Xeon but also GPUs.

   Thrust C++ functional programming library

   FP is nice, hides low level details, backend can be any major parallel platform.

   MATLAB, Mathematica

   easy to use parallelism for operations that they have implemented in parallel, etc.

   CUDA C++ extension and library for Nvidia

   low level access to Nvidia GPUs.

   nvc++

   Nvidia's parallel C++ compiler.

8. The techniques learned here will also be applicable to larger parallel machines -- numbers 2 and 3 on the top 500 list use NVIDIA GPUs.

9. Effectively programming these processors will require in-depth knowledge about parallel programming principles, as well as the parallelism models, communication models, and resource limitations of these processors.

3 Prerequisite

ECSE-2660 CANOS or equivalent, knowledge of C++,.

4 Professor

W. Randolph Franklin. BSc (Toronto), AM, PhD (Harvard)

Office

online only

Phone

+1 (518) 276-6077 (forwards)

Email

frankwr@YOUKNOWTHEDOMAIN

Email is my preferred communication medium.

Sending from non-RPI accounts are fine, but please show your name, at least in the comment field. A subject prefix of #Prob is helpful. GPG encryption is fine.

Web

https://wrf.ecse.rpi.edu/

A quick way to get there is to google RPIWRF.

Office hours

After each online lecture, usually as long as anyone wants to talk. Also by appointment.

5 Course websites

The homepage has lecture summaries, syllabus, homeworks, etc.

6 Reading material

7 Computer systems used

8 Assessment measures, i.e., grades

1. There will be no exams.

2. Each student will make several in-class presentations summarizing some relevant topic.

3. There will be a term project.

9 Remote class procedures

Parallel will be completely virtual. I intend to lecture live, with some supplementary videos. Since this is a small class, students will be encouraged to ask questions, live and with chat during the class. I'll try to save the chat window, but it may be deleted after each class. If you cannot watch the class live, then you may miss any info presented in the chat window.

Try to share your video when talking.

I'll try to use a webex teams space for discussions between class. Operative word is TRY. We may switch to webex teams for classes.

I will maintain a class blog that briefly summarizes each class. Important points will be written down.

I will attempt to record all classes and upload them to mediasite for students to watch or download later. However, this fall, about 10% of classes failed to record properly. If this happens, then you will miss that class.

Depending on the class composition, since it increases learning, there might be graded in-class quizzes. That means, that I would like to do this. However if it causes too much trouble for too many students then I won't.

There will be no exams. Students will be expected to make a in-class presentations and answer questions, and present a final project in class. Just submitting a video for me to play is insufficient because then, how do you answer questions after your talk?

In general, if the conflicting class is not in ECSE, then I expect you to treat my class more seriously, e.g., attend it live more often.

10 Early warning system (EWS)

As required by the Provost, we may post notes about you to EWS, for example, if you're having trouble doing homeworks on time, or miss an exam. E.g., if you tell me that you had to miss a class because of family problems, then I may forward that information to the Dean of Students office.

11 Academic integrity

See the Student Handbook for the general policy. The summary is that students and faculty have to trust each other. After you graduate, your most important possession will be your reputation.

Specifics for this course are as follows.

1. You may collaborate on homeworks, but each team of 1 or 2 people must write up the solution separately (one writeup per team) using their own words. We willingly give hints to anyone who asks.

2. The penalty for two teams handing in identical work is a zero for both.

3. You may collaborate in teams of up to 3 people for the term project.

4. You may get help from anyone for the term project. You may build on a previous project, either your own or someone else's. However you must describe and acknowledge any other work you use, and have the other person's permission, which may be implicit. E.g., my web site gives a blanket permission to use it for nonprofit research or teaching. You must add something creative to the previous work. You must write up the project on your own.

5. However, writing assistance from the Writing Center and similar sources in allowed, if you acknowledge it.

6. The penalty for plagiarism is a zero grade.

7. Cheating will be reported to the Dean of Students Office.

12 Other rules required by RPI

You've seen them in your other classes. Assume that they're included here.

13 Student feedback

Since it's my desire to give you the best possible course in a topic I enjoy teaching, I welcome feedback during (and after) the semester. You may tell me or write me, or contact a third party, such as Prof James Lu, the ECSE undergrad head, or Prof John Wen, the ECSE Dept head.
